Product Specification: Dell Precision 3680 Tower Workstation
Model: Intel Core i7-14700, 16GB RAM, 1TB SSD, NVIDIA RTX A1000, Windows 11 Pro
Overview
The Dell Precision 3680 Tower is a professional workstation designed for exceptional scalability and performance . Powered by a 14th Gen Intel Core i7 processor and NVIDIA RTX A1000 professional graphics, it delivers robust performance for demanding professional applications such as CAD, engineering, and content creation. This configuration features 16GB of DDR5 RAM and a fast 1TB NVMe SSD, all housed in a highly expandable tower chassis .
Technical Specifications
| Component | Details |
|---|---|
| Model | Dell Precision 3680 Tower Workstation |
| Part Number / SKU | cupt4003680s16bn2ojp (Japan reference) / Custom configurable via Dell |
| Form Factor | Tower – Highly expandable design |
| Processor | Intel® Core™ i7-14700 (14th Gen) with vPro® • Cores: 20 Cores (8 Performance-cores + 12 Efficient-cores) • Threads: 28 Threads • Max Turbo Frequency: Up to 5.4 GHz • Smart Cache: 33 MB • Processor Base Power: 65 W |
| Chipset | Intel W680 (Professional workstation chipset) |
| Memory (RAM) | 16 GB DDR5, 4400 MT/s (Non-ECC) • Configuration: 1 x 16 GB (single-channel) • Slots: 4 x DIMM slots • Maximum Supported: Up to 128 GB ECC or non-ECC memory |
| Storage | 1 TB M.2 2280 PCIe NVMe SSD (Gen 4.0), TLC, Class 40, SED Ready |
| Graphics | NVIDIA RTX A1000 (Ampere architecture) – 8 GB GDDR6 • CUDA Cores: 2,304 • RT Cores: 18 (2nd Gen) • Tensor Cores: 72 (3rd Gen) • Memory Interface: 128-bit • Memory Bandwidth: Up to 192 GB/s • Form Factor: Professional, single-slot, low-profile • Outputs: 4 x mini-DisplayPort 1.4 • Max Displays: 4 • Max Resolution: 5K @ 60Hz per display • ISV Certified: Yes, for professional applications |
| Operating System | Windows 11 Pro (64-bit) |
| Power Supply | 500W (80 Plus Platinum) internal PSU (or 300W/1000W options) |
| Audio | Realtek ALC3204, High Definition Audio, internal speaker |
| Ethernet (LAN) | Integrated Gigabit Ethernet Controller (1 GbE) via RJ-45 port; optional 2.5 GbE available |
| Wireless | Intel® Wi-Fi 6E AX211, 2×2, 802.11ax + Bluetooth® 5.3 (included in many configurations) |
| Ports | Front: • 1 x USB 3.2 Gen 1 (5 Gbps) Type-A • 1 x USB 3.2 Gen 1 (5 Gbps) Type-A with PowerShare • 1 x USB 3.2 Gen 2 (10 Gbps) Type-C® • 1 x USB 3.2 Gen 2×2 (20 Gbps) Type-C® with PowerShare • 1 x Universal Audio Jack • 1 x SD Card Slot Rear: |
| Expansion Slots (Internal) |
• 1 x Full-Height Gen5 PCIe x16 slot • 1 x Full-Height Gen3 PCIe x4 slot • 1 x Full-Height Gen4 PCIe x4 open-ended slot • 1 x M.2 2230 slot (for Wi-Fi/Bluetooth) • 2 x M.2 2230/2280 PCIe Gen4 slots (for NVMe SSDs) • 1 x M.2 2280 PCIe Gen3 slot (for NVMe SSD) • 5 x SATA slots (for 3.5-inch HDD/ODD) |
| Drive Bays | Multiple 3.5-inch and 2.5-inch internal bays (expandable via SATA slots) |
| Optical Drive | Configurable – 8x DVD+/-RW 9.5mm Slimline Optical Disk Drive available |
| Chassis | Form Factor: Tower Color: Black Dimensions (H x W x D): 372.9 mm x 173.0 mm x 420.2 mm (14.68″ x 6.81″ x 16.54″) Weight (Minimum): 7.58 kg (16.71 lb) |
| Security |
• Discrete Trusted Platform Module (TPM) 2.0 • Kensington Security Slot • Chassis Intrusion Switch (optional) • SED (Self-Encrypting Drive) support • BIOS security features (passwords, secure boot) |
| Systems Management |
• Intel vPro® Enterprise (with supported processors) • Dell Client Command Suite • Dell Optimizer for Precision |
| ISV Certification | Certified for major ISV applications including AutoCAD, Revit, SolidWorks, CATIA, Creo, Adobe Creative Suite, and more |
| Environmental | Sustainability: ENERGY STAR Qualified, EPEAT Gold with Climate+ |
| Warranty | ✅ 3-YEAR WARRANTY |
| What’s Included | • Dell Precision 3680 Tower Workstation • Power Cord (AC) • Dell USB Optical Mouse – MS116 (Black) • Quick Start Guide & Documentation • (Keyboard may be included depending on configuration; not included on some SKUs) |
Graphics Card Details: NVIDIA RTX A1000
| Specification | Details |
|---|---|
| GPU Architecture | NVIDIA Ampere |
| CUDA Cores | 2,304 |
| RT Cores | 18 (2nd Gen) – Hardware-accelerated ray tracing |
| Tensor Cores | 72 (3rd Gen) – AI acceleration and DLSS |
| Memory | 8 GB GDDR6 |
| Memory Interface | 128-bit |
| Memory Bandwidth | Up to 192 GB/s |
| Form Factor | Low-profile, single-slot |
| Outputs | 4 x mini-DisplayPort 1.4 |
| Max Displays | 4 |
| Max Resolution | 5K @ 60Hz per display |
| PCIe Interface | PCIe 4.0 x8 |
| Power Consumption | 50 W (bus-powered, no additional power connector required) |
| ISV Certification | Yes – Certified for professional applications including CAD, BIM, and DCC |
Key Features Summary
14th Gen Intel Core i7-14700 with vPro®: Powerful 20-core processor (8 P-cores + 12 E-cores) with up to 5.4 GHz turbo frequency – ideal for demanding professional workloads and enterprise manageability .
Professional NVIDIA RTX A1000 Graphics: 8GB GDDR6 VRAM, 2,304 CUDA cores, RT Cores for ray tracing, and Tensor Cores for AI acceleration – ISV-certified for CAD, engineering, and creative applications .
Fast 1TB NVMe Gen4 Storage: High-speed SSD for quick boot times, application loading, and data access .
16GB DDR5 Memory: High-speed memory with upgradeability to 128GB via 4 DIMM slots .
Expandable Tower Design: Spacious tower chassis with Gen5 PCIe x16 slot, multiple PCIe slots, M.2 slots, and SATA bays for extensive future upgrades .
ISV Certification: Guaranteed compatibility and performance for professional software applications .
Intel vPro® Platform: Hardware-based security and remote manageability for enterprise IT deployments .
Modern Connectivity: Comprehensive ports including dual 20Gbps USB-C on front, multiple USB-C on rear, DisplayPort, and optional 2.5Gb Ethernet .
Ray Tracing & AI Capabilities: RTX A1000 enables hardware-accelerated ray tracing for enhanced visualization and Tensor Cores for AI-powered workflows .
Professional-Grade Reliability: Engineered for demanding workloads with rigorous testing and validation .
Dell Optimizer: AI-based optimization for performance, audio, and productivity .
Warranty Availability: 3-year warranty confirmed on reseller SKUs; available as upgrade from Dell .
Ideal For:
Engineers, architects, designers, content creators, and professionals requiring:
✅ ISV-certified workstation performance for CAD, BIM, and creative applications
✅ NVIDIA RTX A1000 graphics with 8GB VRAM, ray tracing, and AI acceleration
✅ Fast 1TB NVMe Gen4 storage for quick access to projects and files
✅ 16GB DDR5 memory (upgradeable to 128GB) for smooth multitasking
✅ Extensive expandability for future upgrades (PCIe Gen5 ready)
✅ Enterprise-grade security with vPro and TPM 2.0
✅ 3-year warranty (select upgrade or specific reseller SKU)
Contact for Quotation:
For pricing, availability, and warranty confirmation for this specific configuration (including 3-year warranty), please contact our sales team.
📱 WhatsApp: 017-910 0013
📧 Email: ecomm@ithinktech.com.my
*PLEASE CHAT WITH US BEFORE PLACING YOUR ORDER
