Product Specification: Dell Pro SFF Desktop
Model: Intel Core Ultra 5 235 vPro AI, 16GB, 1TB SSD, Windows 11 Pro (QCS1250-U5235-16-1TB-W11P)
Overview
The Dell Pro Slim Desktop (QCS1250) is an AI-ready business PC that combines powerful performance with a space-saving design . Powered by an Intel Core Ultra 5 235 vPro processor with a dedicated NPU, it delivers AI-accelerated capabilities for modern productivity applications. This configuration features 16GB of DDR5 RAM and a spacious 1TB NVMe SSD, all housed in a compact, expandable chassis that’s ideal for professional environments .
Technical Specifications
| Component | Details |
|---|---|
| Model | Dell Pro Slim Desktop (QCS1250) |
| Part Number / SKU | bto105_qcs1250_jp / bts105_qcs1250_ndc (similar configs) |
| Form Factor | Slim / Small Form Factor (SFF) Desktop |
| Chassis Color | Black |
| Processor | Intel® Core™ Ultra 5 235 with Intel vPro® (Series 2) • Cores: 14 Cores • Threads: 14 Threads • Max Turbo Frequency: Up to 5.0 GHz • NPU Performance: 13 TOPS (Intel AI Boost) |
| Memory (RAM) | 16 GB DDR5, up to 5600 MT/s • Configuration: 1 x 16 GB (single-channel) • Slots: 2 x DIMM slots (1 free slot) • Maximum Supported: Up to 64 GB |
| Storage | 1 TB M.2 2230/2280 PCIe NVMe SSD (PCIe Gen 4.0) • Slots: 1 x M.2 2230/2280 slot for SSD |
| Graphics | Integrated Intel® Graphics |
| Operating System | Windows 11 Pro (64-bit) |
| Chipset | Intel Q870 (for Core Ultra processors) |
| Power Supply | 180 W, 80 PLUS Bronze Certified internal power supply unit |
| Audio | Realtek ALC3204, High Definition Audio |
| Ethernet (LAN) | Integrated Gigabit Ethernet Controller via RJ-45 port (1 Gbps) |
| Wireless | Not included in base configuration (No Wireless LAN Card) • 1 x M.2 2230 slot available for Wi-Fi and Bluetooth combo card (optional upgrade) |
| Ports | Front: • 2 x USB 2.0 (480 Mbps) Type-A ports • 1 x USB 3.2 Gen 1 (5 Gbps) Type-A port • 1 x USB 3.2 Gen 1 (5 Gbps) Type-C® port (data only) • 1 x Global Headset Jack Rear (for Intel Core Ultra processors): Optional Ports (configurable, mutually exclusive): |
| Expansion Slots | • 1 x Half-Height Gen3 PCIe x16 slot • 2 x Half-Height Gen3 PCIe x1 slots • 1 x M.2 2230 slot for Wi-Fi and Bluetooth combo card • 1 x M.2 2230/2280 slot for solid-state drive • 1 x SATA 3.0 slot for 3.5-inch hard drive • 1 x SATA 3.0 slot for slim optical drive |
| Chassis | Form Factor: Slim Desktop / Small Form Factor Color: Black Dimensions (H x W x D): 303.5 mm x 95 mm x 293 mm (11.95″ x 3.74″ x 11.54″) Weight: Starting at 3.90 kg (8.61 lb) |
| Security | • Discrete Trusted Platform Module (TPM) 2.0 Enabled • Intel vPro® Platform Eligibility • Kensington Security Slot • Padlock Ring |
| Systems Management | Intel vPro® Support (enabled with this processor) |
| Environmental | Sustainability: ENERGY STAR Qualified, EPEAT registered (varies by region) |
| Durability | MIL-STD-810H tested for reliability; redesigned thermals for quieter operation |
| What’s Included | • Dell Pro Slim QCS1250 Desktop • Dell Wired Keyboard – KB216 (region-specific layout) • Dell Wired Mouse – MS116 (Black) • Power Cord (AC) • Quick Start Guide & Documentation |
Key Features Summary
Intel Core Ultra 5 235 with Intel vPro®: Next-generation 14-core processor with dedicated NPU (13 TOPS) for AI-accelerated productivity applications and enhanced performance .
Intel vPro® Platform: Hardware-based security and remote manageability for enterprise IT deployments .
Ample Memory & Storage: 16GB of DDR5-5600 RAM (upgradeable to 64GB) and a spacious 1TB NVMe SSD ensure lightning-fast performance and plenty of storage for files and applications .
AI-Ready Platform: Integrated NPU enables on-device AI acceleration for Windows Studio Effects, real-time transcription, and AI-powered productivity tools .
Space-Saving Design: Compact Slim chassis fits easily in tight spaces while offering extensive expansion capabilities with tool-less access .
Advanced Graphics Connectivity: Supports up to 4 independent displays via DisplayPort 1.4a (HBR3) and HDMI 2.1 ports (with support for optional FRL/DP2.1 modules) .
Modern Connectivity: Wide array of ports including USB-C (front), multiple USB-A, DisplayPort, HDMI, and RJ-45 Ethernet .
Expandability: Three PCIe slots, M.2 slots for SSD and Wi-Fi, and SATA bays for future upgrades .
Enterprise Security: TPM 2.0, Intel vPro platform, Kensington lock slot, and padlock ring for robust hardware-based security .
Military-Grade Durability: MIL-STD-810H tested and redesigned thermals for quieter, reliable operation .
Warranty Flexibility: Base 12-month warranty can be upgraded to 3-year Basic, ProSupport, or ProSupport Plus for long-term coverage .
Ideal For:
Business professionals, power users, developers, and enterprise IT deployments requiring:
✅ AI-accelerated performance with next-generation Intel Core Ultra processor
✅ Compact, space-saving desktop for clutter-free workspaces
✅ Intel vPro platform for enhanced security and remote manageability
✅ 16GB memory (upgradeable to 64GB) for smooth multitasking
✅ Spacious 1TB storage for files and applications
✅ Expandability for future upgrades and customization
✅ Multi-monitor support for enhanced productivity
✅ Long-term reliability with optional 3-year warranty coverage
